激光一体机

特点 FEATURES

本产品为激光与机座完美结合，体积小，功率大，整机人体工程学设计，更适宜首饰行业产品美观、性能稳定、满足长时间连续工作的需要，适用于金属产品的焊接和修补，包括黄金，不锈钢、18K金、铂金、925银等金属This machine is integrated with stand base, very small, high power, is very suitable forewellery, stable quality, can work long time for metal product's welding and repair.including gold, stainless steel. 18k gold. platimum gold and 925 silver

操作说明 OPERATING IN STRUCTIONS

1.打开电源开关，检查电路电源是否正常

2.检查线路是否连接

3点击激光充电，等待激光充电完成

4.打开调试模式进行红光对焦

5.调整红光距离进行试焊

6.打开自动模式进行自动焊接

1. Turn on the power supply and check that the circuit power supply is normal

2.Check if the line is connected

3. Click on the laser to charge, waiting for the laser to charge complete

4.Open debug mode forred focus

5.Adjusting the red light distance to test welding

6.Open automatic mode

技术参数 TECHNICAL PARAMETER

输入电压input voltage: 220v-18A

平均功率average power:80W

脉冲峰值功率pulse peak power: 11kw

大脉冲能量maximum pulse energy:60J

更大脉冲能量(3ms)maximum pulse energy(3ms):25J

脉冲频率pulse frequency: 0-15Hz

外型规格Size:65cm*50*150

重量 Net weight: 90KG
