600型织链机

特点 FEATURES

拥有两对可方便更换的凸轮，用作侧身，双扣链和十字，麻花链转换动作时使用的。侧身链双扣链，十字链，麻花链，仿绳链等链条均可生产。

Two pairs of cams can be easily replaced, used for curb, double curb chain and cabletriple cable to change its movement action, Curb chain, double curb chain, cable chaintriple cable chain, rope chain and other chains can be produced

操作说明 OPERATINGINSTRUCTIONS

1.将模具螺旋槽，线芯，上刀，下刀，上钳，下钳，调整到合适位置，把规格合适的线径调整到螺旋槽里面进行出圈,配合线芯转到合适位置

2调整上钳到合适位置进夹住线圈

3.调整上刀,下刀至合适位置进行线圈切断

4.调整下钳到合适位置进行圈口合拢

5.调整已合口圈进行穿环

1.Adjust the spiral. pin, horizontal knife, vertical knife, pincers, facons to the properposition, insert the wire into the sprial and position it by the pin.

2.Adjust the pincers to clamp the spiral

3.Adjust the horizontal and vertical knife to cut the ring

4.Adjust the facons to make the link

5.Adjust the link to the proper position for welding

技术参数 TECHNICAL PARAMETER

线径参数 Line diameter parameter: 0.1mm -0.4mm

输入电源Inputpower: 220V/50HZ

额定功率Rated power: 400w

更大速度 Maximum speed: 600rmp

外型规格Size:48cm85cm*145cm

净重 Net weight: 110KG
