激光焊接肖邦机

特点 FEATURES

拥有激光自动焊接功能,主要用于生产单扣左右扭，两扣肖邦、三扣肖邦，相比等离子焊接肖邦机效率更高稳定性更强

With automatic laser welding system, mainly used for producing the single and doublecurb chain, double spiga chain, triple spiga chain, it will be much more efficient and stablecompared with laser welding system.

操作说明 OPERATINGINSTRUCTIONS

1.将模具螺旋槽,线芯，上刀，下刀，上钳，下钳，调整到合适位置，把规格合适的线径调整到螺旋槽里面进行出圈,配合线芯转到合适位置

2调整上钳到合适位置进夹住线圈

3.调整上刀,下刀至合适位置进行线圈切断

4.调整下钳到合适位置进行圈口合拢

5.调整吹气针头把圈吹到合适位置

6.调整激光红点对焦到合适位置进行焊接

7.调整已焊接合口圈进行穿环

1.Adjust the spiral, pin, horizontal knife, vertical knife, pincers, facons to the properposition insert the wire into the sprial and position it by the pin.

2.Adjust the pincers to clamp the spiral

3.Adjust the horizontal and vertical knife to cut the ring

4.Adjust the facons to make the link

5.Adjustthe airjets to the proper position

6.Adjustthe laser point to the proper position for welding

7.Pass through the welding link

技术参数 TECHNICAL PARAMETER

线径参数 Line diameterparameter: 0.13mm/0.40mm

输入电源Inputpower: 220V/50HZ

额定功率 Rated power:400W

更大速度Maximum speed; 200rmp

外型规格Size: 48cm*85cm*145cm

净重Net weight:110KG
