四轴车花机

特点 FEATURES

拥有四个可更换的车花刀头，能针对各种链条款式进行平面，倒角或车凹槽来增加链身的闪亮度进行车花也可以订制不同角度刀具进行专门角度车花,本产品具有闪0链，车十字链等一次完成特性，能大大增加生产效率减低企业生产成本Four vertical heads diamond cutting machine prearranged for horizontal heads, suitableor the flat and edges lapping on various medium and small chains.This machine candiamond cut anchor chain and cable chain just by one time, which will be much moreefficient and reduce production cost.

操作说明 OPERATINGINSTRUCTIONS

1.启动电源检查通电是否正常

2.装好要进行车花的链子所对应的模具盘

3.装上对应角度的车花刀具

4.把车花刀具调整到与链之间安全距离，启动刀头，调整刀具到链身上方进行车花5.调整完四面刀具将按钮调整到自动模式进行车花

1.Turn on machine

2.Install the proper disk for corresponding chain

3.Install the tools with correct angle

4. Adiust the tool to the safe distance between the chain, then start the diamond cuttinghead and adjust it to the proper distance for diamond cutting on the chains.5. Switch the machine to automatic working mode after adjusting four side tools

技术参数 TECHNICAL PARAMETER

输入电源Inputpower: 220V/50HZ

额定功率Rated power: 10KW

更大转速 Maximum speed: 24000rpm/min

外型规格 Size:130cmx75cmx198cm

净重Netweight;:800kg
