等离子焊接织链大机

特点 FEATURES

拥有自动焊接功能,机体携带了一个焊枪,是利用电子火花和氲气对准接口放电,而使到接口在瞬间融化结合来达到焊接效果。可针对黄金、铂金、K金、银、不锈钢等进行焊接。侧身链双扣链，十字链，麻花链等链条均可生产。

With automatic welding function, machine equipped with a plasma nozzle, it use electronicsparks and argon alignment interface discharge, and so that the interface in an instantmelt to achieve welding effect. Can be used for gold, platinum, K gold, silver, stainlesssteel welding. Curb chain, double curb chain, cable chain, triple cable chain, rope chainand other chains can be produced.

操作说明 OPERATINGINSTRUCTIONS

1.将模具螺旋槽,线芯，上刀，下刀，上，下钳，调整到合适位置，把规格合适的线径调整

到螺旋横里面进行出圈,配合线芯转到合适位置

2.调整上销到合适位置进夹住线圈

3.调整上刀下刀至合适位置进行线圈切断

4.调整下钳到合适位置进行圈口合拢

5.调整合口圈到合适位置进行焊接

6.调整已焊接合口圈进行穿环

1.Adjust the spiral. pin, horizontal knife, vertical knife, pincers, facons to the properpositioninsert the wire into the sprial and position it by the pin

2.Adjust the pincers to clamp the spiral

3.Adjust the horizontal and vertical knife to cut the ring

4.Adjust the facons to make the link

5.Adjust the link to the proper position for welding

6.Pass through the welding link

技术参数 TECHNICAL PARAMETER

线径参数line diameter parameter: 0.5mm-2.0mm

输入电源Inputpower: 220V/50HZ

额定功率Rated power:1500W

更大速度Maximum speed: 200rpm

外型规格Size:75cm*70cm*195cm

净重Netweight:220kg
