织链大机

特点 FEATURES

此机型主要针对线径较大的链条专门开发的自动化大型织链设备，侧身链，双扣链，十字链麻花链等链条均可生产.

This machine is used for producing big size of curb chain, double curb chain, cable chainand triple cable chain.

操作说明 OPERATINGINSTRUCTIONS

1.将模具螺旋槽,线芯，上刀，下刀，上钳，下钳调整到合适位置，把规格合适的线径调整到螺旋槽里面进行出圈,配合线芯转到合适位置

2.调整上钳到合适位置进夹住线圈

3.调整上刀,下刀至合适位置进行线圈切断

4.调整下钳到合适位置进行圈口合拢

5.调整已合口圈进行穿环

1. Adjust the spiral. pin, horizontal knife, vertical knife, pincers, facons to the properposition insert the wire into the sprial and position it by the pin.

2.Adjust the pincers to clamp the spiral

3.Adjust the horizontal and vertical knife to cut the ring

4.Adjust the facons to make the link

5.Adjust the link to the proper position for welding

技术参数 TECHNICAL PARAMETER

线径卷数line diameter parameter: 0.5mm-2.0mm输入电源Inputpower: 220V/50HZ

额定功率Rated power: 1000W

更大速度Maximum speed: 200rpm

外型规格 Size:70cm*60cm*138cm

净重Net weight;170kg
