车花机

特点 FEATURES

拥有双面可更换的车花刀头，能针对各种链条款式进行平面，倒角或车凹槽来增加链身的闪亮度进行车花也可以订制不同角度刀具进行专门角度车花Two vertical heads diamond cutting machine prearranged for horizontal heads, suitablefor the flat and edges lapping on various medium and small chains.

操作说明 OPERATINGINSTRUCTIONS

1.启动电源检查通电是否正常

2.装好要进行车花的链子所对应的模具盘

3.装上对应角度的车花刀具

4.把车花刀具调整到与链之间安全距离，启动刀头，调整刀具到链身上方进行车花5.调整完两面刀具装按钮调整到自动模式进行车花

1.Turn on machine

2.Install the proper disk for corresponding chain

3.Install the tools with correct angle

4. Adjust the tool to the safe distance between the chain, then start the diamond cuttinahead and adjust it to the proper distance for diamond cutting on the chains.5. Switch the machine to automatic working mode after adiusting two side tools

技术参数 TECHNICAL PARAMETER

参数Inputpower 0.20mm-0.6mm

输入电源Rated power380V/50HZ

额定功率1800W

更大转速Rpm6000-8000rpm/min

外型规格Size120cm*60cm*165cm

净重650kg
