线材成型机

特点 FEATURES

拥有两个速度档位选择和自动绕线功能，操作人员只需将需要成型的线材按顺序从大到小穿进压槽即可成型，无需调整成型槽高低即可成型，本产品拥有成型速度快，操作简单精准度高等特点是生产黄金，白银，K金等金属加工厂理想的机器

with two speed gear selection and automatic winding function, the operator only need toshape the wire from large to small through the groove, no need to adjust the height. Thismachine has high forming speed, easy use and high precision for the production of goldsilver, K gold and other metal.

操作说明 OPERATINGINSTRUCTIONS

1打开电源开关，检查电路电源是否正常

2.检查压线槽表面是否干净

3.打开慢速开关进行运行，同时检查机器是否运作正常

4.把需要成型的线材放到相应大小的槽中进行成型

5.观察已成型线材是否正常，然后进行连续成型

1.Turn on machine

2.Check if groove ofrollers is clean or not

3. Turn on the slow switch for testing and check if machine work properly

4.Insert the wire into groove of proper size

5. Observe whether the formed wire is normal. then make continuous rolling

技术参数 TECHNICAL PARAMETER

线横参数 Lineslotparameters: 10.00mm-1.0mm

输入电源Inputpower: 380V/50HZ

额定功率Rated power: 3000W

外型规格Size:95cm75cm*140cm

净重Netweight: 985kg
